DS-2CD1027G0-L

Name: DS-2CD1027G0-L
SKU: 11132
Availability: InStock

2 MP ColorVu Fixed Bullet Network Camera

₨7,500.00

34 People watching this product now!

Camera

Lens

Lens Type	Fixed focal lens, 2.8 and 4 mm optional
Focal Length & FOV	2.8mm, horizontal FOV 107°, vertical FOV 56°, diagonal FOV 127° 4mm, horizontal FOV 84°, vertical FOV 45°, diagonal FOV 99°
Lens Mount	M12
Iris Type	fixed
Aperture	F1.0
Focus	2.8 mm: 1.7 m to ∞ 4 mm: 2.1 m to ∞

Video

Main Stream	50Hz: 20fps (2560 × 1440) 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440) 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-Stream	50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) * Note: The frame rate of the sub-stream cannot exceed the maximum frame rate of the current main stream.
Video Bit Rate	32Kbps to 8Mbps
Video-Compression	Main stream: H.265+/H.265/H.264+//H.264, sub-stream: H.265/H.264/MJPEG, third stream: H.265/H.264
H.264 Type	BaseLine Profile/Main Profile/High Profile
H.265 Type	Main Profile
Region Of Interest (ROI)	1 fixed region for main stream

Network

Network-Protocol	TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS
Simultaneous Live View	Up to 6 channels
API	APIONVIF (PROFILE S, PROFILE G), ISAPI
User/Host	Up to 32 users. 3 user levels: administrator, operator and user
Safety	Password protection, complicated password, HTTPS encryption, IP address filter, security audit log, basic and digest authentication for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for ONVIF
Client	iVMS-4200, Hik-Connect, Hik-Central
Web Browser	Plug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11; Plug-in free live view: Chrome 45.0+, Firefox 52.0+
Alarm Linkage	Motion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error


Day/Night Mode	Day, Night, Auto, Schedule
Image Settings	Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Wide Dynamic Range (WDR)	Digital WDR
Image Enhancement	BLC/3D DNR/HLC

Interface

Ethernet Interface

1 RJ45 10M/100M self-adaptive Ethernet port

Event

Basic Event	Motion detection, exception (illegal login)
Linkage	Upload to FTP, notify surveillance center, send email, trigger recording, trigger capture *Note: External device is required.

General

Dimension	68.4 × 65.2 × 161.1 mm (2.7" × 2.6" × 6.3")
Power Supply	12 VDC ± 25%, 0.30 A, max. 3.6 W, Ø5.5 mm coaxial power plug, reverse polarity protection PoE: 802.3af, Type 1 Class 3, 36 V to 57 V, 0.20 A to 0.10 A, max. 4.5W
Language	English
Firmware Version	V5.5.82
General Function	Anti-flicker, heartbeat, mirror, privacy masks, flash log, password reset via e-mail, pixel counter
Startup And Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
Package Dimension	172 × 104 × 80 mm (6.8" × 4.1" × 3.1") Approx. 420 g (0.9 lb.)
With Package Weight	Approx. 510g (1.1 lb.)
Storage Conditions	-30°C to 60°C (-22°F to 140°F). Humidity 95% or less (non-condensing)
Reset	Reset via web browser and client software

Approval

Security	Ingression protection: IP67 (IEC 60529-2013)
Safeguard	UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
Environment	CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
EMC	FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
